Nvidia Quadro K5200 8GB GDDR5 PCIe x16 Dual DVI/DP GPU Video Graphics Card Dell R93GX
|
| |
|
| Manufacturer |
Nvidia |
| Model number |
Quadro K5200 |
| Dell P/N |
R93GX |
| SKU |
255700170313 |
| |
|
| Description |
The NVIDIA Quadro K5200 gives you amazing application performance and capability, making it faster and easier
to accelerate 3D models, render complex scenes, and simulate large datasets. 8GB of GDDR5 GPU memory with ultra-fast bandwidth allows you to create and render large, complex models and compute massive datasets. Plus, there’s the all-new display engine that drives up to four displays natively with DisplayPort 1.2 support for ultra-high resolutions like 3840 x 2160 at 60 Hz with 30-bit color. The Quadro K5200 is also fully compatible with NVIDIA Quadro Sync, which allows you to frame-lock multiple displays together, and also supports NVIDIA’s SDI input
and output boards for broadcast or digital cinema production workflows.
Designed and built specifically for professional workstations, NVIDIA Quadro GPUs power more than 200 professional applications across a broad range of industries including manufacturing, media and entertainment, sciences, and energy. Professionals trust them to realize their most ambitious visions— whether its product design, visualization and simulation, or spectacular visual storytelling—and get results to market faster. |
| |
|
| Specifications |
| Form factor |
Single Slot |
| CUDA cores |
2304 |
| Memory |
8GB GDDR5 |
| Memory interface |
256-bit |
| Memory bandwidth |
192GB/s |
| System interface |
PCI Express 3.0 x16 |
| Display Connectors |
DVI-I DL + DVI-D DL + DP 1.2 + DP 1.2 |
| DisplaPort 1.2 |
Yes |
| Max DP 1.2 resolution |
4096x2160 @ 60Hz (directly attached) |
| Max DVI-I DL resolution |
2560x1600 @ 60Hz |
| Max DVI-I SL resolution |
1920x1200 @ 60Hz |
| Max VGA resolution |
2048x1536 @ 85Hz |
| Graphics APIs |
Shader Model 5.0, OpenGL 4.4, DirectX 11 |
| Compute APIs |
CUDA, DirectCompute, OpenCL |
| HDCP Support |
Yes |
| NVIEW |
Yes |
| Thermal Solution |
Ultra-quiet active fasink |
| |
|
| Package |
| Condition |
New |
| Contents |
Video Card, 2x Displayport to DVI cables, DVI to VGA adapter, Power cord, drivers CD |
| |
|
|
