Black Box GigaBase Bulk cable CAT 5e UTP 1000ft EYN851A-PB-1000

Black Box GigaBase Bulk cable CAT 5e UTP 1000ft EYN851A-PB-1000

Price :
$99.99  $89.99
Save: 10% off
Add to Cart:
  • SKU: CBBB002
  • UPC: 822088067320
  • Model: EYN851A-PB-1000
  • Shipping Weight: 10lbs
  • 3 Units in Stock
  • Manufactured by: Black Box

DESCRIPTION

FeaturesSweep tested and characterized to 350 MHz. Extra headroom provides room for growth. CAT5e compliance means dependable compatibility for future applications. Ideal for voice, 10BASE-T, 4-/16-Mbps Token Ring, 100BASE-TX, 100-Mbps TP-PMD, T1, 155-Mbps ATM, 622-Mbps ATM, Gigabit Ethernet, and other high-speed applications. Low attenuation and power-sum crosstalk characteristics over an extended frequency range. Every master pull box or spool is tested for electrical performance. Longitudinal rip cord for easy jacket opening. Save time!This bulk cable features the Accu-Pull Measuring System: Descending sequential foot markings let you know exactly how much is left on the spool. No more guesswork or measuring to see how much cable you have left.

ACR (Minimum at 100 m) — 16.3 dB at 100 MHz; 1.4 dB at 200 MHz
Attenuation (Minimum at 100 m) — 22.0 dB at 100 MHz; 32.4 dB at 200 MHz; 41.0 dB at 300 MHz; 44.9 dB at 350 MHz
Cable Type — 4-pair UTP
Capacitance Unbalance (Maximum) — 3300 pF/Km (Pair to ground)
Characteristic Impedance — 1–350 MHz: 100 ± 15 ohms
Conductor — 24 AWG, solid, bare copper
Conductor Resistance — 93.8 ohm/20° C maximum
Delay Skew (Maximum) — 1–350 MHz: 40 nS/100 m
EL-FEXT (Minimum at 100 m) — 23.8 dB at 100 MHz; 17.7 dB at 200 MHz; 14.2 dB at 300 MHz; 12.9 dB at 350 MHz
NEXT (Minimum at 100 m) — 38.3 dB at 100 MHz; 33.8 dB at 200 MHz; 31.2 dB at 300 MHz; 30.1 dB at 350 MHz
PS-ACR (Minimum at 100 m) — 14.3 dB at 100 MHz
PS-ELFEXT (Minimum at 100 m) — 20.8 dB at 100 MHz; 14.7 dB at 200 MHz; 11.2 dB at 300 MHz; 9.9 dB at 350 MHz
PS-NEXT (Minimum at 100 m) — 36.3 dB at 100 MHz; 31.8 dB at 200 MHz; 29.2 dB at 300 MHz; 28.1 dB at 350 MHz
Return Loss — 20.1 dB at 100 MHz
Velocity of Propagation (Minimum) — 62.1% at 350 MHz

Title
Black Box GigaBase Bulk cable CAT 5e UTP 1000ft EYN851A-PB-1000
Condition
Tested and inspected by our technicians!Fully working!Damaged box(Actual images)
Content
CABLE
Manufacturer
BLACK BOX
Model
EYN851A-PB-1000
MPN
EYN851A-PB-1000
SKU
CBBB002
UPC
822088067320

Condition:

Refurbished
